CRL D15PASSCH Polished Chrome Passage Standard Grade 2 Lever Lockset

• ANSI A156.2 Grade 2
• UL Listed

Finish

Polished Chrome

Handle Length

4-5/8

Type

Standard Duty Lever Lockset

Backset

2-3/4

Handing

Non Handed and Reversible

Function

Passage

UL Listed

Yes

Includes

Strike

Category

Door Accessories

Door Type

Aluminum, Wood, Hollow Metal

Strike Width

1-1/4

Operation Type

F75 Passage Lever

Certification

ANSI A156.2 Grade 2

Door Thickness Range

1-3/8″ To 1-3/4″

Finish/Color

Polished Chrome

Fire Rating (Hour)

3

Strike Height (Inches)

4-7/8

Rosette Base Width (Inches)

3-3/8

Rosette Base Height (Inches)

11/16

Projection

2-1/2

Strike Height

4-7/8

Fire Rating Hour

3

Rosette Base Height

11/16

Rosette Base Width

3-3/8

Product Overview

These CRL Heavy-Duty Commercial Grade 1 and 2 Lever Locksets are non-handed and reversible. These Locksets are UL Listed with a 3-hour fire rating, and fit door thicknesses from 1-3/8″ to 1-3/4″ (35 to 45 mm) with a 2-3/4″ (70 mm) backset. An ANSI 1-1/4″ x 4-7/8″ (32 x 124 mm) Strike is included.

PASSAGE FUNCTION DESCRIPTION:Both levers are always free.

.
